xTool S1 40W _Dark_RA2_Kit-Class I

Name: xTool S1 40W _Dark_RA2_Kit-Class I
SKU: XT-40S1-IR-W

SKU

XT-40S1-IR-W

Manufacturer No

40S1-IR-W

Rating:

80 % of 100

$2,479.00

This product has been discounted from the manufacturer and is no longer available.

Description

xTool S1 20W

Ultra-fine cutting

The xTool S1 features a 20W laser that can easily cut 10mm wood in one pass.
Upgraded structure for increased stability

The enhanced stability of our upgraded guide rail structure and 600mm/s high-speed movement unlock the full potential of the 40W high power laser, resulting in an impressive boost in efficiency.

Revolutionary tech

xTool S1 uses novel encoders and algorithms to establish a precise absolute coordinate layout and display the laser module's position in real time in the software.
Twin-point positioning, camera-like precision

Discover xTool's unique Twin-point positioning technology. Achieving pattern placement with precision rivaling camera methods, all with unmatched ease and accuracy.
Dynamic-focus engraving: perfect on uneven surfaces

xTool S1 boasts a cutting-edge intelligent focusing system for multi-point focus ranging and 3D object automation. Its electric Z-axis dynamically refines focus, delivering a perfect engraving effect like a plane.

Fresh air. Fresh ideas.

Efficient smoke exhaust system.

The high-performance exhaust system, coupled with the exhaust fan, efficiently filters and expels smoke and dust generated during the machine's operation.
Clear air: purify as you create.

Paired with an air purifier, it ensures a healthier workspace by effectively capturing and filtering airborne particles and fumes.

xTool S1 Riser Base - Black

Higher Speed and Accuracy

360°/s (maximum angular speed)

0.45° (precise control)

0-100mm (diameter range)
*360°/s speed is for 37mm diameter cylinder.

*The diameter range here is in the case of engraving with Chuck Rotary.

Compatible with Other Brands

LightBurn

The layout, editing, and control software for common laser cutter. Engraving file format supports NC, BMP, JPG, PNG, DXF, etc.
LaserGRBL

Free laser engraving software that is able to load any image, picture and logo and send to your laser engrave with few clicks.

Small Details. Big Differences.

Soft-pad Jaws

Soft-pad covered on jaws provide a larger friction force, and prevent brittle objects from breaking.
More Choice for Jaws

xTool RA2 Pro comes with double step jaws and single step jaws. Users can also 3D print their own jaws to work with more objects.

Separable Level Tool

Keep the center of objects stable all the time, especially for irregular and extra-long cylinders.
Easy to use

Smart mechanical structure design makes it easier to adjust the support module height and the chuck diameter.

Full Auto Fire Safety Set for Desktop Laser

Wireless Auto Flame Detection

By S1 flame detection and alarm capability, temperature, and position inside the enclosed laser, xTool Fire Safety set is sensitive to any possible dangers of fire.

xTool S1 Infrared Module

Elevate Business with Aesthetics and Originality

Feel Free to Realize Your Creativity in Plastic, Acrylic and Leather

Specification

Product Name	xTool S1 20W with Air Assist and Honeycomb - Black
Product Dimensions	30 x 22.08 x 7.2 inches
Item Weight	44 pounds

Product Name	xTool RA2 Pro
Product Size	321138105mm
Package Size	46018295mm
Package Weight	2.33kg
Compatible with	xTool D1, D1 Pro and other open laser engravers
Gear ratio	Chuck 4:1
Chuck diameter	50mm
Engrave diameter range (Use additional risers)	Roller: 3mm-198mm Chuck: 0mm-100mm Sphere: 25mm-100mm Ring: 11mm-70mm
Software	xTool Creative Space LightBurn LightGRBL

Product Name	xTool S1 1064nm Infrared Laser Module
Package Size	180130130mm
Product Size	11471.1577.2mm
Product Weight	560g
Weight with Package	820g
