Product Features



  • Superior Strength and Stiffness
  • Toughness & Vibration Resistance
  • Exceptional Thermal Resistance
  • Comes with High Temperature Reusable Spool
  • Diameter: 1.75mm +/- 0.03mm


Cautions for Use



  • AMS NOT Compatible
  • Dry out before use
Description

Bambu PA6-CF

Bambu PA6-CF is a carbon fiber reinforced PA6 (Nylon 6) filament. The carbon fiber reinforcement provides significantly high stiffness and strength properties in dry environments and maintains exceptional heat resistance and impact resistance. Similar to other Bambu CF Filaments, these outstanding mechanical properties make it an ideal choice for printing fixtures, clamps, automotive and mechanical components and various structural and engineering parts that used in dry environments.



Impact & Vibration Resistance

Bambu PA6-CF offers excellent impact resistance, ensuring effective vibration resistance for your prints. It is commonly used to print models that need to withstand impact, collision, and vibration.





Printing Tips

  • Bambu PA6-CF needs proper drying before printing: recommended drying temperature is 80 ℃ for 10 hours in a blast drying oven, or 90 ℃ for 12 hours on heat bed. (Do not exceed 100 ℃ because the spool may melt).
  • Bambu PA6-CF will experience a decrease in strength and stiffness after absorbing water,making it not recommended for printing models with high requirements for strength, stiffness, and dimensional stability, especially thin and elongated models. The prints of PA6-CF usually become tougher and more resistant to impacts, drops, and collisions when they get damp, you can dampen and soften the prints in advance if the model requires high toughness.
  • When printing a model with support, it is necessary to remove the support structure within 2 hours to prevent it from being difficult to remove after being damp and softened. Please dry the prints and let them cool down if it is difficult to remove the support, and then remove the support in time.
  • Fully impregnating the surface of the prints with paint, wax and other water-proof coatings can inhibit water absorption and prevent them from becoming soft.
What's in the Box?
Specification
Drying Settings (Blast Drying Oven) 80 °C, 8 - 12 h
Printing and Keeping Container's Humidity < 20% RH (Sealed, with Desiccant)
Nozzle Temperature 260 - 290 °C
Bed Temperature (with Glue) 80 - 100 °C
Printing Speed < 100 mm/s
Melting Temperature 223 °C
Density 1.09 g/cm³
Impact Strength 40.3 ± 2.5 kJ/m²
