RAISE3D E2 IDEX 3D PRINTER WITH 3YR RAISESHIELD
Rating:
0 % of 100
$5,299.00
Raise IDEX Printer
The E2 is a desktop 3D printer with independent dual extruders (IDEX) as it gives E2 the ability to perform more advanced functions, such as Mirror Mode and Duplication Mode, making this printer ideal for professional 3D printing.
- Mirror Mode can print the inverse of a print at the same time as the primary print, saving you additional design and printing time.
- Duplication Mode cuts your printing time in half by printing a primary component and an exact copy simultaneously.
Key points of E2 IDEX Printer:
- IDEX 3D printer features Easy Swap Print Heads for added convenience when performing maintenance or routine printing tasks.
- Raise 3D E2 printer can print with a variety of different filament types at temperatures up to 572°F.
- The printerās unique extruder gear design enables it to use flexible 3D printing materials, such as TPU, more reliably and with better results.
- HEPA air filter makes the E2 IDEX Printer work as a desktop 3D printer, removing toxic nano particles released during printing.
- Built-in 7" touchscreen display for job management, on-screen assistance, and visual model selection.
- Rise E2 printers have Auto Bed Levelling which adjusts the nozzle to make sure the right distance between the bed and the nozzles is maintained during printing.
- The printer has a camera connected to RaiseCloud allowing users to keep track of every print job remotely.
Safety features:
- The E2 IDEX printer has a filament run-out sensor on its extruders to alert when the filament is about to run out, and save the print job.
- A power loss function to save its place and continue printing in the event of a power outage.
Description
-
Auto Bed Leveling and Video-assisted Offset Calibration System
(industry first!) -
Large Build Volume
up to 13Ć9.4Ć9.4 inch (330Ć240Ć240 mm) -
Added Safety Features
E2 detects if a door is opened and immediately pauses the 3D print -
Power Saving Button
turns off the display and LED lights for energy savings -
Flexible Build Plate
for easy removal of 3D printed models -
Wide Variety of Compatible Filament Materials
with a max nozzle temperature of 300ā, a max build plate temperature of 110ā, and fully enclosed build chamber, E2 can print with a variety of 1.75mm filament materials, including PLA, ABS, HIPS, PC, TPU, TPE, Nylon, PETG, ASA, PP, PVA, glass fiber infused, carbon fiber infused, metal fill, and wood fill materials. -
Intuitive User Interface
Raise3D's 7-inch touchscreen control panel will full adjustment control and visual print progress indicator -
Power Loss Recovery
E2 automatically saves progress if there's a power failure and resumes printing when power is restored -
Filament Run-out Sensors
E2 automatically pauses the print if it runs out of filament--just add filament and resume your 3D printing project -
HEPA Air Filtration
removes nano-particles -
Printer Cart (optional upgrade)
Raise3D's mobile cart is a great option for schools and large organizations that plan to share the 3D printer amongst multiple departments. Includes storage space for filament and tools.
Specification
Print technology | Fused Filament Fabrication (FFF) |
---|---|
Print Head System | IDEX |
Filament diameter | Filament diameter |
Print Head Travel Speed | 30ā150 mm/s |
Build plate | Flexible Steel Plate with Buildtak |
Max. build plate temperature | 110ĀŗC |
Heated Bed Material | Silicone |
Build Plate Leveling | Mesh-leveling with Flatness Detection |
Filament Run-out Sensor | Available |
Layer Height | 0.02ā0.25 mm |
Nozzle Diameter | 0.4 mm (Default), 0.2/ 0.6/ 0.8/ 1.0 mm (Available) |
Max Nozzle Temperature | 300ĀŗC |
Connectivity | Wi-Fi, LAN, USB port, Live camera |
Noise Emission (Acoustic) | ļ¼50 dB(A) when building |
Operating Ambient Temperature | 15-30ĀŗC, 10-90% RH non-condensing |
Storage Temperature | -25 to +55ā, 10-90% RH non-condensing |
Filter | HEPA filter with activated charcoa |
Technical Certifications | CB, CE, FCC, RoHS, RCM |
Net Weight | 35.1 kg (77.4 lbs) |
Slicing Software | ideaMaker |
Supported File Types | STL/ OBJ/ 3MF/ OLTP |
Supported OS | WINDOWS/ macOS/ Linux |
Machine Code Type | G CODE |
Material Type | PLA/ ABS/ HIPS/ PC/ TPU/ TPE/ NYLON/ PETG/ ASA/ PP/ PVA/ Glass Fiber Infused/ Carbon Fiber Infused/ Metal Fill/ Wood Fill |
User Interface | 7-inch Touch Screen |
