xTool D1 Pro Blue & Infrared Laser Bundle
Manufacturer ID -P1030254_P5010176
You May Be Wondering - 20W is laser output power, which figures measure the capability of the machine to cut and 120W is the machine power of the laser machine
Higher Accuracy - xTool D1 laser cutter adopts a0.08*0.06 mm ultra-fine compression spot, resulting in detailed and vivid engraving images
xTool D1 Pro 20W Blue & Infrared Laser Bundle with 1064 Laser Module
20W TOP Cutting Capability: Thanks to 20W high power laser output, xTool D1 Pro 20W is a great acrylic cutting machine as powerful as an industrial CNC Cutter. You can do a 10mm wood cutter, 8mm black acrylic cutter at one time. It is ideal for those who have high requirements for laser machine cutting ability. (The cutting capacity is related to the output power of the lazer, not to the power of the machine)
High Accuracy & Speed Laser Engraver Machine: The D1 Pro 20W laser head adopts 0.08mm compressed spot technology and the maximum processing resolution (DPI) reaches 1000, your wood carving is clearer. The unique belt tension adjustment device and steel shaft wheel guide rail design ensure 0.01mm high motion accuracy, 0.02mm repeat positioning accuracy. The maximum processing speed can reach 24000mm/min. With such engraving tools, you can complete your engraving artwork quickly and well.
Safe & Easy to Use: xTool D1 Pro 20W laser head comes with a hood, eye protection design prevents the lazer from affecting eyes. When laser engravers are moved or tilted during processing, laser engraver machine will stop immediately; flame alarm function can prevent wood burning, you can rest assured for wood carving; the built-in large-capacity SD card supports offline processing; in addition to supporting USB connection, it also supports WiFi connection to get rid of the shackles of wires.
High Quality, Long Service Life: Using blue light semiconductor laser, service life is up to 10000 hours. Excellent control algorithm reduces vibration and prolongs motor life. High-precision wear-resistant slide rails and 4-way hard limiters prevent equipment from colliding with edges and reduce unnecessary wear and tear. The built-in integrated auxiliary blowing nozzle reduces pollution of laser head protection lens, and prevents lens breakage and laser power attenuation caused by pollution.
Type | xTool D1 Pro-20W | xTool D1 Pro-10W |
---|---|---|
Machine Power | 120W | 60W |
Laser Electric Power | 84W | 40W |
Laser Module Output Power | 20W | 10W |
Laser Spot | 0.08*0.10mm | 0.08*0.06 mm |
Routing Speed | 400 mm/s | 400 mm/s |
Working Area | 430 * 390 mm (16.93 * 15.35 inch) | 430*400 mm(16.93*15.75 inch) |
Max. Workpiece Height | 50 mm (2 inch) | 50 mm (2 inch) |
Max. Workpiece Height with X risers | 50mm+X*45mm(each set riser height column) | 50mm+X*45mm(each set riser height column) |
Connecting Interfaces | USB/Wi-Fi/TF Card | USB/Wi-Fi/TF Card |
Certification | FCC / FDA / CE | FCC / FDA / CE |
Operating Systems | Windows/macOS | Windows/macOS |
Control Software | xTool Creative Space / LightBurn | xTool Creative Space / LightBurn |
File Type(s) | SVG/DXF/JPG/JPEG/PNG/BMP/TIF/CR2, etc. | SVG/DXF/JPG/JPEG/PNG/BMP/TIF/CR2, etc. |
Compatible Accessories | RA2 Pro Air Assist Set xTool Smoke Purifier Honeycomb Working Panel Set Enclosure xToolCare for xTool D1 Pro 20W RA1 |
RA2 Pro Air Assist Set Smoke Purifier Honeycomb Working Panel Set Enclosure xToolCare for xTool D1 Pro 10W RA1 |
